Built-in 100A Solar Charger
Wide PV Input Voltage Range 40-500V
Feed-in to Grid
Dual AC Output
Support Lithium/Lead-acid Battery
Lithium Battery Activation
Detachable Dust Cover
WiFi Monitoring(built-in)
| Model | XN3624-MAX |
| AC Input | |
| Rated Input Voltage (VAC) | 208 / 220 / 230 / 240; L + N + PE |
| Voltage Range (VAC) | 90~280±3 (normal mode); 170~280±3 (UPS mode) |
| Frequency (Hz) | 50 / 60 (Auto Adaptive) |
| AC Output | |
| Rated Capacity (kW) | 3.6 |
| Surge Power (kVA) | 7.2 |
| Voltage (VAC) | 208 / 220 / 230 / 240 |
| Power Factor (PF) | 1 |
| Frequency | 50/60Hz±0.1% |
| Switch Time (ms) | 10 (APP/UPS mode) / 20 (GEN mode) |
| Wave Form | Pure Sine Wave |
| Overload Capacity (Battery Mode) | 60s@102%-110% load; 10s@110%-130% load; 3s@130%-150% load; 0.2s@>150% load |
| Max. Efficiency (Battery Mode) | 92.7%@24VDC |
| Parallel Quantity | NA |
| Charger (PV / AC) | |
| Solar Charger Type | MPPT |
| Max PV input Current / Input Power | 18A / 5000W |
| MPPT Range@Operating Voltage (VDC) | 40-450 |
| Max PV Open Circuit Voltage (VDC) | 500 |
| Max PV Charge Current (A) | 100 |
| Max AC Charge Current (A) | 100 |
| Max. Charge Current (PV + AC) (A) | 100 |
| Battery | |
| Rated Voltage (VDC) | 24 |
| Floating Charge Voltage (VDC) | 27 |
| Overcharge Protection (VDC) | 30.5 |
| Battery Type | Lithium and Lead-acid |
| Interface | |
| HMI | LCD |
| Interface | RS485 / CAN / RS232 |
| Monitoring | WiFi (built-in) |
| General Data | |
| Ingress Protection | IP21 |
| Operating Temperature | -10 ℃- 60 ℃ |
| Relative Humidity | 5% ~ 95% (Non-condensing) |
| Storage Temperature | -15 ℃ - 60 ℃ |
| Net Weight (kg) | 6.2 |
| Dimensions (H*W*D) | 420*284*94mm |
| Max. Operating Altitude | 4000m (Derating above 1000m) |
