DIN-Rail Logger
| ICA400-06N | ICA100-06N-EU | |||||
| Remote Communication Interface | 4G | WIFI | ||||
| Working Frequency | Band 1/3/3/8/34/39/40/41 | 2.412GHz～2.484GHz | ||||
| Antenna | Internal | |||||
| Data Interface | RS485 | |||||
| Working Voltage | DC5~12V | |||||
| Working Power | 3W | 1.5W | ||||
| SIM Card | MicroSIM | —— | ||||
| memory | 8M Flash | 2M Flash | ||||
| Temperature | -25℃～65℃ | |||||
| Humidity | 90%(No Condensation） | |||||
| Shell Material | PC+ABS_V0 | |||||
| Number of Connections | 1 | |||||
| Serial Communication Rate | 9600bps（1200~115200bps Configurable） | |||||
| Data Acquisition Interval | Default：5mins(1-15mins Configurable) | |||||
| User Configuration | APP/Bluetooth | |||||
| Firmware Upgrade | Remote | |||||
| Access to Third-Party Platforms | Configurable(MQTT) | |||||
| Others | Real-time Monitoring, Bluetooth Debugging, Inverter Upgrade | |||||
